20/20 Imaging Digital X-ray System C-FPH (Hybrid Flat Panel, Cesium) 17x17 Tethered

SPECIFICATIONS

•  Warranty: 5 years
•  Imaging Area: 17" x 17"
•  Line pair per mm: 3.6
•  Wireless & tethered connectivity
•  Cassette sized
•  Battery Life: >3.5hrs
•  9.50 lbs
•  Pixel Pitch: 139um
•  Off-center Imaging
•  Dimensions: 18.11”x18.11”x0.6”
•  A/D conversion: 16-bit

Revolutionary 17x17 TFT Cesium Flat Panel Detector Technology
"Point, Click & View" Process > 300 Images per Hour
16 Bit High Quality Image Transfer Interface
Advanced Image Processing - Artifact Free & Consistent High Image Quality

DELL Precision 3420 High Resolution Diagnostic ACQ/Viewer Workstation
DICOM Image Acquire and QC Software w/Grid Suppression
Chiropractic Analysis and Diagnostic Software
Window Level, Magnify, Zoom, Rotate,
• Tools include Cobb Angle and Measurements
• Georges's Line, Adv. Orthogonal, & Gonstead
Windows 10 Operating System
Intel Core i5-6500 Processor (Quad Core, 3.26GHz Turbo, 6MB with HD Graphics)
1TB 7200RPM SATA Hard Drive
Tower Case
8GB 2133MHz DDR4 for Precision Workstations
19" DELL 1MP Widescreen Panel Display
Onboard Intel DVMT Video Card
CDRW Drive
Integrated Ethernet Controller and 56k Modem
550VA Uninterruptible Power Supply
USB 2.0 Interface
Integrates to all DICOM Compatible PACS Software

Universal Detector Grid Cabinet
Retrofit Add-On to Existing Upright Structure (specific to OEM mounting hole pattern)
Aluminum Encased Grid w/Overlay 17x17 10:1, 103 LPI, 40-72 focal distance
Custom Detector/Grid Cabinet Overlay

Opal-Rad DICOM Image Viewer Software Package
Allows access to patient images from 2 CC WEB in- office/ web locations
VIZTEK Chiropractic Analysis and Diagnostic Software
Window Level, Magnify, Zoom, Rotate,
• Tools include Cobb Angle and Measurements
• Georges's Line, Adv. Orthogonal, & Gonstead
